Comprehensive Gear and Shaft Manufacturing Process: From Forging to Hard Finishing

The production of gears and shafts involves multiple advanced manufacturing stages designed to achieve superior strength, precision, and performance. At Belon Gears, we integrate traditional metal-forming methods with state-of-the-art machining and finishing technologies such as forging, casting, 5-axis machining, hobbing, shaping, broaching, shaving, hard cutting, grinding, lapping, and skiving to deliver world-class transmission components for various industries.

1. Material Forming: Forging and Casting
The process starts with forming the gear blanks and shafts:

• Forging enhances the metal’s internal structure and mechanical strength by compressing it under high temperature and pressure, ideal for gears requiring high torque capacity and fatigue resistance.

• Casting enables the creation of complex or large gear shapes by pouring molten metal into precision molds, offering flexibility in geometry and material selection.

2. Precision Machining and Gear Cutting
After forming, precision machining defines the geometry and accuracy of the gear.

• 5 Axis Machining provides exceptional flexibility, allowing intricate angles and multiple surfaces to be machined in a single setup, improving both precision and productivity.

• Hobbing, milling, and shaping are widely used for gear tooth generation. Hobbing suits spur and helical gears, shaping works for internal gears, and milling supports prototypes or special designs.

• Broaching is used for producing keyways, internal splines, or specific gear profiles efficiently and accurately.

3. Finishing and Hard Machining Processes
Once the teeth are cut, several finishing operations refine surface quality and tooth accuracy.

• Gear Shaving removes small material layers to correct minor profile errors left from hobbing and to improve gear meshing.

• Hard Cutting is a high-precision machining method performed after heat treatment, allowing direct finishing of hardened gears without the need for grinding in some cases. It offers better productivity, reduced tool wear, and maintains surface integrity while ensuring tight tolerances.

• Grinding remains essential for gears demanding ultra-high precision, smooth surfaces, and minimal noise, particularly in automotive and aerospace gearboxes.

• Lapping enhances contact smoothness by running paired gears together under controlled pressure, ensuring quiet and efficient operation.

• Skiving, combining aspects of hobbing and shaping, is ideal for high-speed internal gear finishing with superior accuracy.

4. Shaft Manufacturing and Heat Treatment
Shafts are machined through turning, milling, and grinding to achieve perfect straightness and concentricity. Following machining, heat treatment methods—such as carburizing, nitriding, or induction hardening—enhance wear resistance, surface hardness, and overall strength.

5. Quality Inspection and Assembly
Every component undergoes strict quality control using CMMs, gear measuring centers, and surface testers to ensure dimensional precision and consistency. Final assembly and testing verify load capacity, smooth rotation, and reliability.

At Belon Gears, we combine forging, casting, hard cutting, and precision finishing to provide a complete manufacturing solution for gears and shafts. Our integrated approach guarantees each component meets the highest standards of performance, longevity, and efficiency—supporting demanding sectors such as robotics, heavy machinery, and transportation worldwide.
