Bevel gear workshop was founded at 1996, who is the first one importing USA UMAC technology for hypoid gears, equipped with 120 staff, successfully obtained total 17 inventions and 3 Patents. We have adopted CNC machine tools along the whole production line including lathing, grinding, lapping, inspection. This allow us to assure interchangeability of spiral bevel gears and meet requirements in different applications.

door of bevel gear worshop 1

Glance Of Bevel Gear Workshop: 10000㎡

Module: 0.5-35, Dimeter: 20-1600, Accuracy: ISO5-8

glance of bevel gear workshop  (1)
glance of bevel gear workshop  (2)

Main Production Equipment

Gleason Phoenix II 275G

Gleason Phoenix II 275G

Module: 1-8

HRH: 1:200

Accuracy: AGMA13

Gleason-Pfauter P600/800G

Diameter: 800

Module: 20

Accuracy: ISO5

Gleason-Pfauter P 600 800G
ZDCY CNC Profile Grinding Machine YK2050

ZDCY CNC Profile Grinding Machine

Spiral Bevel Gears

Diameter:500mm

Module:12

Accuracy: GB5

ZDCY CNC Profile Grinding Machine

Spiral Bevel gear

Diameter: 1000mm

Module: 20

Accuracy: GB5

ZDCY CNC Profile Grinding Machine YK2050
ZDCY CNC Profile Grinding Machine YK20160

ZDCY CNC Profile Grinding Machine for spiral bevel gears

Diameter: 1600mm

Module: 30

Precision grade :GB5

Heat Treat Equipment

We used Japan Takasago vacuum carburizing, which makes the heat treat depth and hardness be uniform and with bright surfaces, greatly increase gears life and decrease noises.

Vacuum carburizing heat treat
